onsemi HGTG11N120CND
Manufacturer:
onsemi
Mfr. Part #:
HGTG11N120CND
Package:
TO-247AC-3
Customer #:
Description:
298W 1.2kV NPT (Non-Punch Through) TO-247AC-3 Single IGBTs RoHS
Datasheet:
onsemi HGTG11N120CND
Products Specifications
Manufacturer:
Package:
TO-247AC-3
Td(off):
240ns
Pd - Power Dissipation:
298W
Td(on):
26ns
Collector-Emitter Breakdown Voltage (Vces):
1.2kV
Input Capacitance(Cies):
-
IGBT Type:
NPT (Non-Punch Through)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
6V@90uA
Gate Charge(Qg):
120nC@15V
Operating Temperature:
-55℃~+150℃@(Tj)
Reverse Recovery Time(trr):
70ns
Switching Energy(Eoff):
1.3mJ
Turn-On Energy (Eon):
950uJ
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
onsemi
19033 Products
onsemi, founded in 1999, has become one of the world's leading semiconductor solution providers through acquisitions and organic growth. It primarily produces power management, analog signal processing, logic ICs, discrete components, and sensors.
