onsemi FGB40T65SPD-F085
Manufacturer:
onsemi
Mfr. Part #:
FGB40T65SPD-F085
Package:
D2PAK-3
Customer #:
Key Attributes:
IGBT 650V D2PAK-3
Description:
IGBT FS (Field Stop) 650V 267W Surface Mount D2PAK-3
Datasheet:
onsemi FGB40T65SPD-F085
Products Specifications
Manufacturer:
Package:
D2PAK-3
Td(off):
35ns
Pd - Power Dissipation:
267W
Td(on):
18ns
Collector-Emitter Breakdown Voltage (Vces):
650V
Input Capacitance(Cies):
1.52nF@30V
IGBT Type:
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
4V@40mA
Gate Charge(Qg):
36nC@40A,15V
Operating Temperature:
-55℃~+175℃
Reverse Recovery Time(trr):
206ns
Switching Energy(Eoff):
280uJ
Turn-On Energy (Eon):
970uJ
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
onsemi
19033 Products
onsemi, founded in 1999, has become one of the world's leading semiconductor solution providers through acquisitions and organic growth. It primarily produces power management, analog signal processing, logic ICs, discrete components, and sensors.
