SparkFun Electronics COM-13952
Manufacturer:
SparkFun Electronics
Mfr. Part #:
COM-13952
Package:
PDIP-14
Customer #:
Description:
Schmitt trigger 20uA 120ns@15V,50pF 3V~18V 6 1 PDIP-14 Gates and Inverters RoHS
Datasheet:
SparkFun Electronics COM-13952
Products Specifications
Manufacturer:
Package:
PDIP-14
Operating Temperature:
-55℃~+125℃
Input Logic Level - Low:
2.8V~7.4V
Input Logic Level - High:
3.6V~10.8V
Input Type:
Schmitt trigger
Quiescent Current(Iq):
20uA
Propagation Delay:
120ns@15V,50pF
Voltage - Supply:
3V~18V
Number of Circuits:
6
Current - Output High(IOH):
6.8mA
Number of Channels:
1
Current - Output Low(IOL):
6.8mA
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1 |
| Sales Unit | Piece |
