onsemi FGL40N120ANDTU
Manufacturer:
onsemi
Mfr. Part #:
FGL40N120ANDTU
Package:
TO-264-3
Customer #:
Key Attributes:
IGBT 1.2kV 64A TO-264-3
Description:
IGBT NPT (Non-Punch Through) 1.2kV 64A 500W Through Hole TO-264-3
Datasheet:
onsemi FGL40N120ANDTU
Products Specifications
Manufacturer:
Package:
TO-264-3
Td(off):
110ns
Pd - Power Dissipation:
500W
Td(on):
15ns
Collector-Emitter Breakdown Voltage (Vces):
1.2kV
Reverse Transfer Capacitance (Cres):
125pF
IGBT Type:
NPT (Non-Punch Through)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
3.5V@250uA
Gate Charge(Qg):
220nC@15V
Operating Temperature:
-55℃~+150℃@(Tj)
Reverse Recovery Time(trr):
75ns
Switching Energy(Eoff):
1.1mJ
Turn-On Energy (Eon):
2.3mJ
Input Capacitance(Cies):
3.2nF
Pulsed Current- Forward(Ifm):
240A
Output Capacitance(Coes):
370pF
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 25 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
