AGMSEMI AGM400D170B6TC
Manufacturer:
AGMSEMI
Asian Brands
Mfr. Part #:
AGM400D170B6TC
Package:
Screw Terminals
Customer #:
Key Attributes:
IGBT Module, Freewheeling Diodes
Description:
1.76kW 1.7kV FS (Field Stop) Screw Terminals Single IGBTs RoHS
Datasheet:
AGMSEMI AGM400D170B6TC
Products Specifications
Manufacturer:
Package:
Screw Terminals
Pd - Power Dissipation:
1.76kW
Td(off):
690ns
Td(on):
170ns
Collector-Emitter Breakdown Voltage (Vces):
1.7kV
Reverse Transfer Capacitance (Cres):
900pF
IGBT Type:
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
5V@12mA
Gate Charge(Qg):
2.1uC@15V
Operating Temperature:
-40℃~+150℃
Reverse Recovery Time(trr):
1.38us
Switching Energy(Eoff):
58mJ
Turn-On Energy (Eon):
173mJ
Input Capacitance(Cies):
29.4nF
Pulsed Current- Forward(Ifm):
600A
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 10 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
AGMSEMI
609 Products
AGMSEMI Core Control Electronic Technology Co., Ltd.
(hereinafter referred to as "AGM-Semi") is a leading designer and marketer of modern high-power semiconductor devices in China, specializing in the design, production, and marketing of a wide range of high-power semiconductor devices and power-integrated devices. AGM-Semi is based on independent innovation, owns independent intellectual property rights, and is committed to the "AGM-Semi" independent product brand. At present, the company specializes in the R&D, design, production, testing, quality assessment, sales, and service of super-junction MOSFETs, NPT-IGBT, and trench-type high-power MOS devices. AGM-Semi has established design and operation centers, sales companies, and outsourcing chip flow bases, finished product packaging bases, and finished product testing bases in mainland China and Hong Kong respectively, and has a perfect quality control assurance system to ensure the consistency and stability of product quality.
