TI UCC21222DR
Manufacturer:
TI
Mfr. Part #:
UCC21222DR
Package:
SOIC-16
Customer #:
Key Attributes:
Isolated dual-channel gate driver (with dead time)
Description:
2 SOIC-16 Gate Drivers RoHS
Products Specifications
Manufacturer:
Package:
SOIC-16
Input Logic Level - Low:
0.8V~1.25V
Peak Output Current(Source):
4A
Peak Output Current(Sink):
6A
Isolation voltage(Vrms):
3000
Quiescent Current(Iq):
2mA
number of channels:
2
Input Voltage (Vin):
3V~5.5V
Driven Configuration:
Low Side;High Side;Half-Bridge
Operating Temperature:
-40℃~+130℃@(Tj)
Propagation Delay tpLH:
40ns
Propagation Delay tpHL:
40ns
Voltage - Supply (Driver):
9.2V~18V
Fall Time:
12ns
Load Type:
IGBT;MOSFET
Input Logic Level - High:
1.6V~2V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8542399000 |
| USHTS | 8542390001 |
| TARIC | 8542399000 |
| CAHTS | 8542390000 |
| BRHTS | 85423999 |
| INHTS | 85423900 |
| MXHTS | 8542.39.99 |
