HUAYI HYG032N03LR1C1

HUAYI HYG032N03LR1C1

Name: HUAYI HYG032N03LR1C1
Brand: HUAYI

Manufacturer: HUAYI Asian Brands

Mfr. Part #: HYG032N03LR1C1

Package: DFN-8(3x3)

Customer #:

Key Attributes: Single N-Channel, Current: 55A, Voltage: 30V

Description: 30V 55A 5.5mΩ@4.5V 2.5V@250uA 23W DFN-8(3x3) Single FETs, MOSFETs RoHS

Datasheet: HUAYI HYG032N03LR1C1

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

HUAYI

Package:

DFN-8(3x3)

Drain to Source Voltage:

30V

Current - Continuous Drain(Id):

55A

Operating Temperature -:

-55℃~+175℃

RDS(on):

5.5mΩ@4.5V

Gate Threshold Voltage (Vgs(th)):

2.5V@250uA

Reverse Transfer Capacitance (Crss@Vds):

277pF

Number:

Output Capacitance(Coss):

332pF

Input Capacitance(Ciss):

2.872nF

Pd - Power Dissipation:

23W

Gate Charge(Qg):

61nC@10V

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	3000
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	-
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
