TI UCC23514SDWVR

TI UCC23514SDWVR

Name: TI UCC23514SDWVR
Brand: TI

Manufacturer: TI

Mfr. Part #: UCC23514SDWVR

Package: SOIC-8

Customer #:

Key Attributes: 4-A Source, 5-A Sink, 5.0-kVRMs Opto-Compatible Single Channel Isolated Gate Drivers

Description: 4.5A 28ns 14V~33V 25ns 5.3A SOIC-8 Isolators - Gate Drivers RoHS

Products Specifications

Category:

Isolators/Isolators - Gate Drivers

Manufacturer:

Package:

SOIC-8

Operating Temperature:

-40℃~+150℃@(Tj)

Propagation Delay(tpd):

105ns;105ns

Isolation voltage(Vrms):

5000

Load Type:

IGBT;MOSFET

Current - Output High(IOH):

4.5A

Rise Time:

28ns

Voltage - Supply:

14V~33V

Fall Time:

25ns

CMTI(kV/us):

150kV/us

Number of Channels:

Current - Output Low(IOL):

5.3A

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	1000
Sales Unit	Piece
