PANJIT 2N7002KDW_R1_00001
Manufacturer:
PANJIT
Mfr. Part #:
2N7002KDW_R1_00001
Package:
SOT-363
Customer #:
Description:
N-Channel Array 60V 115mA 200mW Surface Mount SOT-363
Datasheet:
PANJIT 2N7002KDW_R1_00001
Products Specifications
Manufacturer:
Package:
SOT-363
Configuration:
-
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
115mA
Operating Temperature -:
-55℃~+150℃
RDS(on):
4Ω@4.5V,200mA
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
10pF
Number:
2 N-Channel
Output Capacitance(Coss):
35pF
Input Capacitance(Ciss):
40pF
Pd - Power Dissipation:
200mW
Gate Charge(Qg):
800pC@4.5V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
