PANJIT PJE8405_R1_00001
Manufacturer:
PANJIT
Asian Brands
Mfr. Part #:
PJE8405_R1_00001
Package:
SOT-523
Customer #:
Key Attributes:
MOSFET P-CH 30V 0.5A SOT-523
Description:
P-Channel 30V 0.5A 300mW Surface Mount SOT-523
Datasheet:
PANJIT PJE8405_R1_00001
Products Specifications
Manufacturer:
Package:
SOT-523
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
500mA
Operating Temperature -:
-55℃~+150℃
RDS(on):
990mΩ@1.8V
Gate Threshold Voltage (Vgs(th)):
1.3V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
10pF@15V
Number:
1 P-Channel
Input Capacitance(Ciss):
137pF@15V
Pd - Power Dissipation:
300mW
Gate Charge(Qg):
1.6nC@15V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 4000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
