Orient OR-3H4-4GB-TA1-G-(GK)

Orient OR-3H4-4GB-TA1-G-(GK)

Name: Orient OR-3H4-4GB-TA1-G-(GK)
Brand: Orient

Manufacturer: Orient Asian Brands

Mfr. Part #: OR-3H4-4GB-TA1-G-(GK)

Package: SOP-16-4.4mm

Customer #:

Key Attributes: Photo coupler

Description: 50mA 400mV@8mA,2.4mA 80V 6V DC SOP-16-4.4mm Transistor, Photovoltaic Output Optoisolators RoHS

Datasheet: Orient OR-3H4-4GB-TA1-G-(GK)

Products Specifications

Category:

Isolators/Optocouplers, Optoisolators/Transistor, Photovoltaic Output Optoisolators

Manufacturer:

Orient

Package:

SOP-16-4.4mm

Rise time:

3us

Output Current:

50mA

Fall time:

4us

Vce Saturation(VCE(sat)):

400mV@8mA,2.4mA

Operating Temperature:

-55℃~+125℃

Load Voltage:

80V

Reverse Voltage:

Current transfer ratio:

400%;20%

Forward Current(If):

50mA

Number of Channels:

Pd - Power Dissipation:

200mW

Load Type:

Phototransistor

Input type:

Isolation Voltage(Vrms):

3.75kV

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	2000
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	-
CNHTS	8541490000
USHTS	8541491010
TARIC	8541490000
CAHTS	8541490090
BRHTS	85414900
INHTS	85414900
MXHTS	8541.40.02

About Product

Get Best Price

Inquiry

Negotiate

Payment

Shipping

Orient

117 Products

Asian Brand

Orient, founded in 1998, is a national high-tech enterprise specializing in the research, development, and manufacturing of optoelectronic wafers and optocouplers. It possesses core chip technology and has a complete IDM industrial chain structure. The company mainly produces optocouplers, isolated drivers, and sensors.
