onsemi AFGY160T65SPD-B4
Manufacturer:
onsemi
Mfr. Part #:
AFGY160T65SPD-B4
Package:
TO-247-3
Customer #:
Key Attributes:
IGBT 650V 240A TO-247-3
Description:
IGBT FS (Field Stop) 650V 240A 882W Through Hole TO-247-3
Datasheet:
onsemi AFGY160T65SPD-B4
Products Specifications
Manufacturer:
Package:
TO-247-3
Td(off):
98ns
Pd - Power Dissipation:
882W
Td(on):
53ns
Collector-Emitter Breakdown Voltage (Vces):
650V
Reverse Transfer Capacitance (Cres):
55pF
IGBT Type:
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
4.3V@160mA
Gate Charge(Qg):
245nC
Operating Temperature:
-55℃~+175℃@(Tj)
Reverse Recovery Time(trr):
132ns
Switching Energy(Eoff):
5.7mJ
Turn-On Energy (Eon):
12.4mJ
Input Capacitance(Cies):
6.71nF
Pulsed Current- Forward(Ifm):
240A
Output Capacitance(Coes):
450pF
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
