MICROCHIP MSC080SMA120S

MICROCHIP MSC080SMA120S

Name: MICROCHIP MSC080SMA120S
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: MSC080SMA120S

Package: D3PAK

Customer #:

Description: 1.2kV 40A 100mΩ 2.8V 231W D3PAK Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP MSC080SMA120S

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

MICROCHIP

Package:

D3PAK

Drain to Source Voltage:

1.2kV

Current - Continuous Drain(Id):

40A

Operating Temperature -:

-55℃~+175℃

RDS(on):

100mΩ

Gate Threshold Voltage (Vgs(th)):

2.8V

Type:

N-Channel

Reverse Transfer Capacitance (Crss@Vds):

6.2pF

Input Capacitance(Ciss):

1.1nF

Output Capacitance(Coss):

91pF

Pd - Power Dissipation:

231W

Gate Charge(Qg):

72nC

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	400
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	-
USHTS	-
TARIC	-
CAHTS	-
BRHTS	-
INHTS	-
MXHTS	-
