Lewa Micro LW13N90SK
Manufacturer:
Lewa Micro
Asian Brands
Mfr. Part #:
LW13N90SK
Package:
TO-247
Customer #:
Description:
900V 13A 800mΩ@10V 5V@250uA 297W TO-247 Single FETs, MOSFETs RoHS
Datasheet:
Lewa Micro LW13N90SK
Products Specifications
Manufacturer:
Package:
TO-247
Drain to Source Voltage:
900V
Current - Continuous Drain(Id):
13A
RDS(on):
800mΩ@10V
Gate Threshold Voltage (Vgs(th)):
5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
40pF
Output Capacitance(Coss):
370pF
Input Capacitance(Ciss):
3.45nF
Pd - Power Dissipation:
297W
Gate Charge(Qg):
76nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Lewa Micro
277 Products
Lewa Micro is a semiconductor design company based in Shanghai, with branches in Shenzhen and Wuxi. Its main product lines include high-voltage VDMOS, medium- and low-voltage trench MOS, medium- and low-voltage SGT-MOS, LDOs, and MCU series.
