Wolfspeed CCB021M12FM3T

Wolfspeed CCB021M12FM3T

Name: Wolfspeed CCB021M12FM3T
Brand: Wolfspeed

Manufacturer: Wolfspeed

Mfr. Part #: CCB021M12FM3T

Package: Module

Customer #:

Description: 1.2kV 30A 27.9mΩ@15V 3.6V@18mA Module Single FETs, MOSFETs RoHS

Datasheet: Wolfspeed CCB021M12FM3T

Products Specifications

Manufacturer:

Wolfspeed

Package:

Module

Drain to Source Voltage:

1.2kV

Current - Continuous Drain(Id):

30A

Operating Temperature -:

-40℃~+150℃

RDS(on):

27.9mΩ@15V

Gate Threshold Voltage (Vgs(th)):

3.6V@18mA

Reverse Transfer Capacitance (Crss@Vds):

16pF

Output Capacitance(Coss):

209pF

Input Capacitance(Ciss):

4.9nF
