Wolfspeed WAB300M12BM3
Manufacturer:
Wolfspeed
Mfr. Part #:
WAB300M12BM3
Package:
Module
Customer #:
Description:
1.2kV 382A 5.2mΩ@15V 3.6V@92mA 938W Module Single FETs, MOSFETs RoHS
Datasheet:
Wolfspeed WAB300M12BM3
Products Specifications
Manufacturer:
Package:
Module
Drain to Source Voltage:
1.2kV
Current - Continuous Drain(Id):
382A
RDS(on):
5.2mΩ@15V
Operating Temperature -:
-40℃~+175℃
Gate Threshold Voltage (Vgs(th)):
3.6V@92mA
Reverse Transfer Capacitance (Crss@Vds):
50pF
Input Capacitance(Ciss):
24.5nF
Output Capacitance(Coss):
970pF
Pd - Power Dissipation:
938W
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Wolfspeed
738 Products
Wolfspeed was founded in 1987 as the power and RF division of Cree and officially rebranded to Wolfspeed in 2021. The company focuses on silicon carbide (SiC) and gallium nitride (GaN) technologies, primarily producing wide bandgap semiconductor materials, power devices, and RF devices.
