Sungine CD4070BP
Manufacturer:
Sungine
Asian Brands
Mfr. Part #:
CD4070BP
Package:
SOP-14
Customer #:
Key Attributes:
4-to-2 Input Exclusive OR Gate IC
Description:
XOR Gate IC 4 Channel SOP-14
Datasheet:
Sungine CD4070BP
Products Specifications
Manufacturer:
Package:
SOP-14
Input Logic Level - High:
3.5V;7V;11V
Operating Temperature:
-10℃~+70℃
Input Logic Level - Low:
1.5V;3V;4V
Series:
4000 Series
Output Logic Level - Low:
50mV
Output Logic Level - High:
4.95V;9.95V;14.95V
Quiescent Current(Iq):
4uA
Propagation Delay:
185ns@5V,50pF
Voltage - Supply:
3V~18V
Current - Output High(IOH):
6.8mA
Number of Channels:
4;2
Current - Output Low(IOL):
6.8mA
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Sungine
87 Products
Sungine, established in 2005 with a registered capital of 25 million RMB, is a high-tech enterprise dedicated to the independent research, design, and testing of high-performance, highly reliable, and ultra-stable integrated circuit products in China. The company primarily produces a series of chips including encoders, isolators, motor drivers, high-performance op-amps, A/D converters, interface circuits, references, low-power MCUs, Darlington transistors, reset circuits, PWM controllers, and LLC controllers.
