PANJIT PJF60R980E_T0_00001
Manufacturer:
PANJIT
Asian Brands
Mfr. Part #:
PJF60R980E_T0_00001
Package:
ITO-220AB
Customer #:
Description:
600V 4A 980mΩ@10V,1.5A 4V@250uA 1 N-channel ITO-220AB Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJF60R980E_T0_00001
Products Specifications
Manufacturer:
Package:
ITO-220AB
Drain to Source Voltage:
600V
Current - Continuous Drain(Id):
4A
Operating Temperature -:
-55℃~+150℃
RDS(on):
980mΩ@10V,1.5A
Gate Threshold Voltage (Vgs(th)):
4V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
41.7pF
Number:
1 N-channel
Output Capacitance(Coss):
311pF
Input Capacitance(Ciss):
300pF
Pd - Power Dissipation:
-
Gate Charge(Qg):
14.4nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
