PANJIT PJQ4848P_R2_00001
Manufacturer:
PANJIT
Mfr. Part #:
PJQ4848P_R2_00001
Package:
DFN3333-8
Customer #:
Description:
40V 37A 20mΩ@4.5V,6A 2.5V@250uA 2 N-Channel 33W DFN3333-8 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJQ4848P_R2_00001
Products Specifications
Manufacturer:
Package:
DFN3333-8
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
37A
Operating Temperature -:
-55℃~+150℃
RDS(on):
20mΩ@4.5V,6A
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
84pF
Number:
2 N-Channel
Output Capacitance(Coss):
117pF
Input Capacitance(Ciss):
1.04nF
Pd - Power Dissipation:
33W
Gate Charge(Qg):
10nC@4.5V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
