PANJIT PJQ5846-AU_R2_000A1
Manufacturer:
PANJIT
Mfr. Part #:
PJQ5846-AU_R2_000A1
Package:
DFN5060B-8
Customer #:
Description:
40V 40A 10.5mΩ@10V 2.5V@250uA 2 N-Channel 38.5W DFN5060B-8 Single FETs, MOSFETs RoHS
Datasheet:
PANJIT PJQ5846-AU_R2_000A1
Products Specifications
Manufacturer:
Package:
DFN5060B-8
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
40A
Operating Temperature -:
-55℃~+175℃
RDS(on):
10.5mΩ@10V
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
88pF
Number:
2 N-Channel
Output Capacitance(Coss):
134pF
Input Capacitance(Ciss):
1.258nF
Pd - Power Dissipation:
38.5W
Gate Charge(Qg):
22nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
PANJIT
1418 Products
Innovation, Development, Responsibility, Sustainability
PANJIT is a public company founded in May 1986. We are a discrete manufacturer, a member of Electronic Industry Citizenship Coalition (EICC), and have ISO/TS-16949, ISO-9001, OHSAS-18001 certifications.
PANJIT is vertical integrated. We self-design and produce the wafer and manufacture our products. With insight observation and core technologies, PANJIT is able to continuously launch low profile products and accurate power rating devices which conforms to the customer needs.
PANJIT commits to serve customers with the best service, thus we have established sales offices worldwide. We have sites in North America, Germany, Korea and China which allows us to provide better and prompt service.
