onsemi NXH200B100H4F2SG
Manufacturer:
onsemi
Mfr. Part #:
NXH200B100H4F2SG
Package:
PIM-36(56.7x48)
Customer #:
Description:
93W 1kV FS (Field Stop) PIM-36(56.7x48) Single IGBTs RoHS
Datasheet:
onsemi NXH200B100H4F2SG
Products Specifications
Manufacturer:
Package:
PIM-36(56.7x48)
Pd - Power Dissipation:
93W
Collector-Emitter Breakdown Voltage (Vces):
1kV
Input Capacitance(Cies):
6.523nF@20V
IGBT Type:
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
2.4V@15V,100A
Operating Temperature:
-40℃~+150℃@(Tj)
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
onsemi
19033 Products
onsemi, founded in 1999, has become one of the world's leading semiconductor solution providers through acquisitions and organic growth. It primarily produces power management, analog signal processing, logic ICs, discrete components, and sensors.
