onsemi NXH300B100H4Q2F2S1G
Manufacturer:
onsemi
Mfr. Part #:
NXH300B100H4Q2F2S1G
Package:
Q2PACK-53(47x93)
Customer #:
Description:
194W 1.118kV FS (Field Stop) Q2PACK-53(47x93) Single IGBTs RoHS
Datasheet:
onsemi NXH300B100H4Q2F2S1G
Products Specifications
Manufacturer:
Package:
Q2PACK-53(47x93)
Pd - Power Dissipation:
194W
Collector-Emitter Breakdown Voltage (Vces):
1.118kV
Input Capacitance(Cies):
6.323nF@20V
IGBT Type:
FS (Field Stop)
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
2.25V@15V,100A
Operating Temperature:
-40℃~+175℃@(Tj)
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
