MIRACLE POWER MSJ001B
Manufacturer:
MIRACLE POWER
Asian Brands
Mfr. Part #:
MSJ001B
Package:
TO-263
Customer #:
Key Attributes:
MOSFET N-CH 200V 109A TO-263
Description:
N-Channel 200V 109A 312W Surface Mount TO-263
Datasheet:
MIRACLE POWER MSJ001B
Products Specifications
Manufacturer:
Package:
TO-263
Drain to Source Voltage:
200V
Current - Continuous Drain(Id):
109A
RDS(on):
10mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
4.5V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
17pF
Pd - Power Dissipation:
312W
Input Capacitance(Ciss):
8.788nF
Output Capacitance(Coss):
455pF
Gate Charge(Qg):
122nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
