MEGSINE MDPX17270609D21
Manufacturer:
MEGSINE
Asian Brands
Mfr. Part #:
MDPX17270609D21
Package:
SMD-6P,2x1.3mm
Customer #:
Key Attributes:
Diplexer For 690-960MHz/1710-3700MHz
Description:
25dB 20dB SMD-6P,2x1.3mm RF Multiplexers RoHS
Datasheet:
MEGSINE MDPX17270609D21
Products Specifications
Category:
Manufacturer:
Package:
SMD-6P,2x1.3mm
High band insertion loss (Max):
0.35dB
Low Band Attenuation (Min):
25dB
Low band return loss (Min):
10dB
Operating Temperature:
-40℃~+85℃
Low band insertion loss (Max):
0.35dB
High Band Attenuation (Min):
20dB
High band return loss (Min):
10dB
High band range:
1.71GHz~2.7GHz
Low band range:
690MHz~960MHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8548000001 |
| USHTS | 8548000000 |
| TARIC | 8548009099 |
| CAHTS | 8548000000 |
| BRHTS | 85480010 |
| INHTS | 85480000 |
| MXHTS | 8548.10.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
MEGSINE
190 Products
Shenzhen MEGSINE Technology Co., Ltd.
(hereinafter referred to as "MEGSINE") was established in 2012. It is a high-tech enterprise focusing on the research, development, production and sales of 4G/5G RF passive chips and RF front-end chips. MEGSINE masters the core process and design technology of RF passive chips and SIP chips, has the industry's professional model algorithm and development process, and can provide filters, power dividers, couplers, 3dB bridges, baluns, duplexers, multiplexers, filter components, RF modules and other products designed and developed based on IPD, LTCC, MEMS, ceramic mixed pressure plates and other processes in large quantities, covering frequencies from 10M to 100GHz. The products are small in size and highly integrated, and are widely used in wireless communications, navigation, radar, drones and other fields.
