MASPOWER MS220N10JDT0
Manufacturer:
MASPOWER
Asian Brands
Mfr. Part #:
MS220N10JDT0
Package:
TO-220
Customer #:
Key Attributes:
MOSFET 100V 220A TO-220
Description:
100V 220A 1.9mΩ@10V 3V 272W TO-220 Single FETs, MOSFETs RoHS
Datasheet:
MASPOWER MS220N10JDT0
Products Specifications
Manufacturer:
Package:
TO-220
Drain to Source Voltage:
100V
Current - Continuous Drain(Id):
220A
RDS(on):
1.9mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
3V
Reverse Transfer Capacitance (Crss@Vds):
52pF
Input Capacitance(Ciss):
12.3nF
Output Capacitance(Coss):
1.435nF
Pd - Power Dissipation:
272W
Gate Charge(Qg):
176nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
