MASPOWER MS20N50FS
Manufacturer:
MASPOWER
Asian Brands
Mfr. Part #:
MS20N50FS
Package:
TO-220F
Customer #:
Key Attributes:
MOSFET N-CH 500V 20A TO-220F
Description:
N-Channel 500V 20A 31.7W Through Hole TO-220F
Datasheet:
MASPOWER MS20N50FS
Products Specifications
Manufacturer:
Package:
TO-220F
Drain to Source Voltage:
500V
Current - Continuous Drain(Id):
20A
Operating Temperature -:
-55℃~+150℃
RDS(on):
200mΩ@10V
Gate Threshold Voltage (Vgs(th)):
4V@250uA
Reverse Transfer Capacitance (Crss@Vds):
7pF
Number:
1 N-channel
Output Capacitance(Coss):
260pF
Input Capacitance(Ciss):
2.85nF
Pd - Power Dissipation:
31.7W
Gate Charge(Qg):
48.7nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
