MACOM MAFL-011024
Manufacturer:
MACOM
Mfr. Part #:
MAFL-011024
Package:
SMD-11P
Customer #:
Description:
45dB 45dB SMD-11P RF Multiplexers RoHS
Datasheet:
MACOM MAFL-011024
Products Specifications
Category:
Manufacturer:
Package:
SMD-11P
High band insertion loss (Max):
1.2dB
Low Band Attenuation (Min):
45dB
Low band return loss (Min):
12dB
Operating Temperature:
-40℃~+85℃
High Band Attenuation (Min):
45dB
Low band insertion loss (Max):
1.1dB
High band return loss (Min):
12dB
High band range:
108MHz~1.002GHz
Low band range:
5MHz~85MHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 200 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8548000001 |
| USHTS | 8548000000 |
| TARIC | 8548009099 |
| CAHTS | 8548000000 |
| BRHTS | 85480010 |
| INHTS | 85480000 |
| MXHTS | 8548.10.01 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
MACOM
2509 Products
Headquartered in Lowell, Massachusetts, MACOM is certified to the ISO9001 international quality standard and ISO14001 environmental management standard. MACOM has multiple design centers, Si, GaAs and InP fabrication, manufacturing, assembly and test, and operational facilities throughout North America, Europe, Asia and Australia. Click here to view our facilities. In addition, MACOM offers foundry services that represents a key core competency within our business. The foundry provides access to, and control of our broad range of proprietary technologies in an asset light, cost effective structure.
