Joint Tech Elec F1003WR-S-20PNLNG1GT0R
Manufacturer:
Joint Tech Elec
Asian Brands
Mfr. Part #:
F1003WR-S-20PNLNG1GT0R
Package:
SMD,P=1mm,Surface Mount,Right Angle
Customer #:
Description:
FFC/FPC Connector 20 Position 1mm Pitch Top Contact Surface Mount, Right Angle
Datasheet:
Joint Tech Elec F1003WR-S-20PNLNG1GT0R
Products Specifications
Manufacturer:
Package:
SMD,P=1mm,Surface Mount,Right Angle
Locking Feature:
Slide Lock
Number of Contacts:
20P
Pitch:
1mm
Contact Type:
Top Contact
Mounting Type:
Surface Mount, Right Angle
FFC, FCB Thickness:
0.3mm
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1500 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8536901100 |
| USHTS | 8536908585 |
| TARIC | 8536901000 |
| CAHTS | 8536900090 |
| BRHTS | 85369010 |
| INHTS | 85369010 |
| MXHTS | 8536.90.11 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Joint Tech Elec
1417 Products
HR (Joint Tech Elec) was founded in 1984 in Taiwan, China, by Chairman Jinyi Xie. In 1998, the company expanded and established additional factories and production lines in Dongguan, Guangdong. The company primarily produces precision connectors and terminals.
