JingYang TNM03K20BX
Manufacturer:
JingYang
Asian Brands
Mfr. Part #:
TNM03K20BX
Package:
DFN1006-3L
Customer #:
Key Attributes:
MOSFET N-CH 20V 1.2A DFN1006-3L
Description:
N-Channel 20V 1.2A 160mW Surface Mount DFN1006-3L
Datasheet:
JingYang TNM03K20BX
Products Specifications
Manufacturer:
Package:
DFN1006-3L
Drain to Source Voltage:
20V
Current - Continuous Drain(Id):
1.2A
RDS(on):
400mΩ@1.8V,0.35A
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
700mV
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
6pF@10V
Number:
1 N-channel
Output Capacitance(Coss):
9pF
Input Capacitance(Ciss):
43pF@10V
Pd - Power Dissipation:
160mW
Gate Charge(Qg):
2nC@4.5V
Additional Information
| Type | Details |
|---|---|
| Minimum | 10 |
| Multiple | 10 |
| Standard Packaging | 10000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
