JingYang TNM3K60FEX
Manufacturer:
JingYang
Asian Brands
Mfr. Part #:
TNM3K60FEX
Package:
SOT-523
Customer #:
Key Attributes:
MOSFET N-CH 60V 0.3A SOT-523
Description:
N-Channel 60V 0.3A 0.15W Surface Mount SOT-523
Datasheet:
JingYang TNM3K60FEX
Products Specifications
Manufacturer:
Package:
SOT-523
Drain to Source Voltage:
60V
Current - Continuous Drain(Id):
300mA
Operating Temperature -:
-55℃~+150℃
RDS(on):
2Ω@10V,0.25A
Gate Threshold Voltage (Vgs(th)):
1.1V
Reverse Transfer Capacitance (Crss@Vds):
5.5pF
Number:
1 N-channel
Output Capacitance(Coss):
10pF
Input Capacitance(Ciss):
16pF
Pd - Power Dissipation:
150mW
Gate Charge(Qg):
1.8nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 20 |
| Multiple | 20 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
JingYang
349 Products
Shenzhen Jingyang Electronics Co., Ltd.
(hereafter referred to as "JYELECTRONICS" or "Shenzhen JingYang") was established in 2006 and has specialized in IC design, production, sales, and system integration for many years. The company operates several wholly-owned subsidiaries and holding companies and holds nearly 100 valid patents and other intellectual property rights. It is recognized as a leading "circuit and system protection expert" in the industry. JYELECTRONICS offers a wide range of products, including ESD devices, TVS components, LED display driver chips, MOSFETs, diodes, triodes, power management chips, interface chips, and more. These products find applications in various areas such as computers, televisions, network communications, smart wearables, security monitoring, home appliances, industrial control, new energy vehicles, and power tools. JYELECTRONICS is committed to the business philosophy of "customer first, quality first, and integrity-based." JYELECTRONICS strives
