HUAYI HYG080N10LS1P
Manufacturer:
HUAYI
Asian Brands
Mfr. Part #:
HYG080N10LS1P
Package:
TO-220FB-3L
Customer #:
Description:
100V 90A 11.2mΩ@4.5V 1V 1 N-channel 150W TO-220FB-3L Single FETs, MOSFETs RoHS
Datasheet:
HUAYI HYG080N10LS1P
Products Specifications
Manufacturer:
Package:
TO-220FB-3L
Drain to Source Voltage:
100V
Current - Continuous Drain(Id):
90A
Operating Temperature -:
-55℃~+175℃
RDS(on):
11.2mΩ@4.5V
Gate Threshold Voltage (Vgs(th)):
1V
Reverse Transfer Capacitance (Crss@Vds):
43pF@25V
Number:
1 N-channel
Input Capacitance(Ciss):
2.09nF
Pd - Power Dissipation:
150W
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
HUAYI
323 Products
HUAYI, also known as Hymexa, was established in 2017 and is a high-tech enterprise under the Huatian Electronics Group, focusing on the research, design, packaging, testing, and sales of semiconductor power devices. Its main product lines include MOSFET, Trench MOSFET, and SGT MOSFET.
