GOFORD G75P04M
Manufacturer:
GOFORD
Asian Brands
Mfr. Part #:
G75P04M
Package:
TO-263
Customer #:
Key Attributes:
MOSFET P-CH 40V 320A TO-263
Description:
P-Channel 40V 320A 306W Surface Mount TO-263
Datasheet:
GOFORD G75P04M
Products Specifications
Manufacturer:
Package:
TO-263
Configuration:
-
Drain to Source Voltage:
40V
Current - Continuous Drain(Id):
80A
Operating Temperature -:
-55℃~+150℃
RDS(on):
8.5mΩ@4.5V
Gate Threshold Voltage (Vgs(th)):
2.5V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
668pF
Number:
1 P-Channel
Output Capacitance(Coss):
698pF
Input Capacitance(Ciss):
6.516nF
Pd - Power Dissipation:
306W
Gate Charge(Qg):
106nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 800 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
