Gainsil GS8722-FR
Manufacturer:
Gainsil
Asian Brands
Mfr. Part #:
GS8722-FR
Package:
DFN-8(2x2)
Customer #:
Key Attributes:
CMOS Rail-to-Rail IO Opamps
Description:
3.5mV 1pA 9V/us 82dB 11MHz 2 Rail-to-Rail Input, Rail-to-Rail Output DFN-8(2x2) Amplifiers RoHS
Products Specifications
Manufacturer:
Package:
DFN-8(2x2)
Vos - Input Offset Voltage:
3.5mV
Input offset current drift(Ios TC):
-
Ib - Input Bias Current:
1pA
Slew Rate:
9V/us
Quiescent Current(Iq):
1.1mA
Common Mode Rejection Ratio(CMRR):
82dB
Operating Temperature:
-40℃~+125℃
Output Current:
55mA
Voltage - Supply:
-1.05V~2.75V;2.1V~5.5V
Gain Bandwidth Product:
11MHz
Input Offset Voltage Drift(Vos TC):
2.4uV/℃
Maximum Power Supply Range (Vdd-Vss):
7.5V
Number of Channels:
2
Rail To Rail:
Rail-to-Rail Input, Rail-to-Rail Output
Input Offset Current(Ios):
1pA
Noise density(eN):
8nV/√Hz@10kHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8542339000 |
| USHTS | 8542330001 |
| TARIC | 8542339000 |
| CAHTS | 8542330000 |
| BRHTS | 85423390 |
| INHTS | 85423300 |
| MXHTS | 8542.33.99 |
