Gainsil GS6552-SR
Manufacturer:
Gainsil
Asian Brands
Mfr. Part #:
GS6552-SR
Package:
SOP-8
Customer #:
Key Attributes:
1.8MHz Zero-Drift CMOS Rail-to-Rail IO Opamp with RF Filter
Description:
5uV 20pA 0.95V/us 110dB 1.8MHz 2 Rail-to-Rail Input, Rail-to-Rail Output SOP-8 Amplifiers RoHS
Products Specifications
Manufacturer:
Package:
SOP-8
Vos - Input Offset Voltage:
5uV
Ib - Input Bias Current:
20pA
Slew Rate:
0.95V/us
Quiescent Current(Iq):
220uA
Common Mode Rejection Ratio(CMRR):
110dB
Output Current:
65mA
Operating Temperature:
-45℃~+125℃
Voltage - Supply:
1.8V~5.5V;-2.75V~-900mV;900mV~2.75V
Gain Bandwidth Product:
1.8MHz
Input Offset Voltage Drift(Vos TC):
5nV/℃
Maximum Power Supply Range (Vdd-Vss):
5.5V
Number of Channels:
2
Rail To Rail:
Rail-to-Rail Input, Rail-to-Rail Output
Input Offset Current(Ios):
10pA
Noise density(eN):
38nV/√Hz@1kHz
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 4000 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8542339000 |
| USHTS | 8542330001 |
| TARIC | 8542339000 |
| CAHTS | 8542330000 |
| BRHTS | 85423390 |
| INHTS | 85423300 |
| MXHTS | 8542.33.99 |
