TI LM5105SD/NOPB
Manufacturer:
TI
Mfr. Part #:
LM5105SD/NOPB
Package:
WSON-10-EP(4x4)
Customer #:
Key Attributes:
Half-Bridge Gate Driver With Programmable Dead Time
Description:
1.8A 8V~14V WSON-10-EP(4x4) Gate Drivers RoHS
Products Specifications
Manufacturer:
Package:
WSON-10-EP(4x4)
Propagation Delay tpLH:
595ns
Propagation Delay tpHL:
26ns
Rise Time:
15ns
Peak Output Current(Sink):
1.6A
Features:
Under Voltage Protection
Current - Output High(IOH):
1.8A
Fall Time:
15ns
Quiescent Current(Iq):
600uA
Load Type:
MOSFET
Voltage - Supply:
8V~14V
Input Logic Level - High:
1.8V~2.2V
Operating Temperature:
-40℃~+125℃
Driven Configuration:
Half-Bridge
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 1000 |
| Sales Unit | Piece |
