Products Specifications
Manufacturer:
Package:
TO-252
Drain to Source Voltage:
650V
Current - Continuous Drain(Id):
4A
RDS(on):
2.5Ω@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
2V
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
3.5pF@25V
Number:
1 N-channel
Output Capacitance(Coss):
53pF
Input Capacitance(Ciss):
610pF@25V
Pd - Power Dissipation:
75W
Gate Charge(Qg):
10nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 2500 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
XCH
1042 Products
Shenzhen XCH Semiconductor Co., Ltd. was established in June 2010. It is a semiconductor device manufacturing enterprise integrating R&D, production and sales. The Jiangsu factory was established in May 1995 and is registered in Rugao City, Jiangsu Province, the hometown of longevity in China. The factory covers an area of ??30,000 square meters, with an annual production capacity of 10 billion devices and 12 product lines. The company's main products are diodes, high-voltage silicon stacks, bridge rectifiers, MOSFETs, protection devices, transistors and other semiconductor devices.
