XCH XCHS1005
Manufacturer:
XCH
Asian Brands
Mfr. Part #:
XCHS1005
Package:
SOT-23
Customer #:
Key Attributes:
MOSFET N-CH 100V 4.5A SOT-23
Description:
N-Channel 100V 4.5A Surface Mount SOT-23
Datasheet:
XCH XCHS1005
Products Specifications
Manufacturer:
Package:
SOT-23
Configuration:
-
Drain to Source Voltage:
100V
Current - Continuous Drain(Id):
4.5A
RDS(on):
95mΩ@10V
Operating Temperature -:
-55℃~+150℃
Gate Threshold Voltage (Vgs(th)):
1.95V@250uA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
21.4pF
Number:
1 N-channel
Pd - Power Dissipation:
1W
Input Capacitance(Ciss):
196pF
Output Capacitance(Coss):
25.9pF
Gate Charge(Qg):
4.3nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 20 |
| Multiple | 20 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
XCH
1042 Products
Shenzhen XCH Semiconductor Co., Ltd. was established in June 2010. It is a semiconductor device manufacturing enterprise integrating R&D, production and sales. The Jiangsu factory was established in May 1995 and is registered in Rugao City, Jiangsu Province, the hometown of longevity in China. The factory covers an area of ??30,000 square meters, with an annual production capacity of 10 billion devices and 12 product lines. The company's main products are diodes, high-voltage silicon stacks, bridge rectifiers, MOSFETs, protection devices, transistors and other semiconductor devices.
