Wolfspeed CAS350M12BM3
Manufacturer:
Wolfspeed
Mfr. Part #:
CAS350M12BM3
Package:
-
Customer #:
Description:
1.2kV 417A 5.2mΩ@15V 3.6V@85mA Single FETs, MOSFETs RoHS
Datasheet:
Wolfspeed CAS350M12BM3
Products Specifications
Manufacturer:
Package:
-
Drain to Source Voltage:
1.2kV
Current - Continuous Drain(Id):
417A
RDS(on):
5.2mΩ@15V
Operating Temperature -:
-40℃~+175℃
Gate Threshold Voltage (Vgs(th)):
3.6V@85mA
Reverse Transfer Capacitance (Crss@Vds):
44.5pF
Output Capacitance(Coss):
1.8nF
Input Capacitance(Ciss):
25.7nF
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Wolfspeed
738 Products
Wolfspeed was founded in 1987 as the power and RF division of Cree and officially rebranded to Wolfspeed in 2021. The company focuses on silicon carbide (SiC) and gallium nitride (GaN) technologies, primarily producing wide bandgap semiconductor materials, power devices, and RF devices.
