Wolfspeed CCB032M12FM3
Manufacturer:
Wolfspeed
Mfr. Part #:
CCB032M12FM3
Package:
-
Customer #:
Description:
1.2kV 30A 42.6mΩ@15V 3.6V@11.5mA Single FETs, MOSFETs
Datasheet:
Wolfspeed CCB032M12FM3
Products Specifications
Manufacturer:
Package:
-
Drain to Source Voltage:
1.2kV
Current - Continuous Drain(Id):
30A
Operating Temperature -:
-40℃~+150℃
RDS(on):
42.6mΩ@15V
Gate Threshold Voltage (Vgs(th)):
3.6V@11.5mA
Reverse Transfer Capacitance (Crss@Vds):
14pF
Input Capacitance(Ciss):
3.4nF
Output Capacitance(Coss):
144pF
Gate Charge(Qg):
118nC@15V
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
Wolfspeed
738 Products
Wolfspeed was founded in 1987 as the power and RF division of Cree and officially rebranded to Wolfspeed in 2021. The company focuses on silicon carbide (SiC) and gallium nitride (GaN) technologies, primarily producing wide bandgap semiconductor materials, power devices, and RF devices.
