VBsemi Elec NTGS3136PT1G-VB
Manufacturer:
VBsemi Elec
Asian Brands
Mfr. Part #:
NTGS3136PT1G-VB
Package:
TSOP-6
Customer #:
Key Attributes:
MOSFET P-CH 30V 4.8A TSOP-6
Description:
P-Channel 30V 4.8A 2W Surface Mount TSOP-6
Datasheet:
VBsemi Elec NTGS3136PT1G-VB
Products Specifications
Manufacturer:
Package:
TSOP-6
Drain to Source Voltage:
30V
Current - Continuous Drain(Id):
4.8A
Operating Temperature -:
-55℃~+150℃
RDS(on):
49mΩ@10V;54mΩ@4.5V
Gate Threshold Voltage (Vgs(th)):
2V@250uA
Type:
P-Channel
Reverse Transfer Capacitance (Crss@Vds):
63pF
Number:
1 P-Channel
Output Capacitance(Coss):
80pF
Input Capacitance(Ciss):
450pF
Pd - Power Dissipation:
2W
Gate Charge(Qg):
10nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 5 |
| Multiple | 5 |
| Standard Packaging | 3000 |
| Sales Unit | Piece |
