VBsemi Elec VBQA1102N
Manufacturer:
VBsemi Elec
Asian Brands
Mfr. Part #:
VBQA1102N
Package:
DFN5x6-8
Customer #:
Key Attributes:
MOSFET N-CH 100V 30A DFN5x6-8
Description:
N-Channel 100V 30A 60W Surface Mount DFN5x6-8
Datasheet:
VBsemi Elec VBQA1102N
Products Specifications
Manufacturer:
Package:
DFN5x6-8
Drain to Source Voltage:
100V
Current - Continuous Drain(Id):
30A
Operating Temperature -:
-55℃~+150℃
RDS(on):
17mΩ@10V
Gate Threshold Voltage (Vgs(th)):
3V
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
11.2pF
Number:
1 N-channel
Output Capacitance(Coss):
132pF
Input Capacitance(Ciss):
1.47nF
Pd - Power Dissipation:
60W
Gate Charge(Qg):
20nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 5000 |
| Sales Unit | Piece |
