onsemi FGY120T65SPD-F085
Manufacturer:
onsemi
Mfr. Part #:
FGY120T65SPD-F085
Package:
TO-247-3
Customer #:
Key Attributes:
Field Stop Trench IGBT With Soft Fast Recovery Diode
Description:
882W 650V TO-247-3 Single IGBTs RoHS
Datasheet:
onsemi FGY120T65SPD-F085
Products Specifications
Manufacturer:
Package:
TO-247-3
Pd - Power Dissipation:
882W
Td(off):
102ns
Td(on):
53ns
Collector-Emitter Breakdown Voltage (Vces):
650V
Reverse Transfer Capacitance (Cres):
50pF
Input Capacitance(Cies):
6.81nF
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
4.2V@120mA
Gate Charge(Qg):
162nC@15V
Operating Temperature:
-55℃~+175℃
Output Capacitance(Coes):
440pF
Reverse Recovery Time(trr):
123ns
Switching Energy(Eoff):
3.5mJ
Turn-On Energy (Eon):
6.8mJ
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 20 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
