onsemi NGTB50N60FWG
Manufacturer:
onsemi
Mfr. Part #:
NGTB50N60FWG
Package:
TO-247
Customer #:
Description:
223W 600V TO-247 Single IGBTs RoHS
Datasheet:
onsemi NGTB50N60FWG
Products Specifications
Manufacturer:
Package:
TO-247
Pd - Power Dissipation:
223W
Td(off):
285ns
Td(on):
117ns
Collector-Emitter Breakdown Voltage (Vces):
600V
Reverse Transfer Capacitance (Cres):
170pF
Gate-Emitter Threshold Voltage (Vge(th)@Ic):
4.5V@350uA
Gate Charge(Qg):
310nC@15V
Operating Temperature:
-55℃~+150℃
Reverse Recovery Time(trr):
77ns
Switching Energy(Eoff):
1.2mJ
Turn-On Energy (Eon):
1.1mJ
Input Capacitance(Cies):
7.3nF
Pulsed Current- Forward(Ifm):
200A
Output Capacitance(Coes):
275pF
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 30 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541600000 |
| USHTS | 8541600080 |
| TARIC | 8541600000 |
| CAHTS | 8541600010 |
| BRHTS | 85416010 |
| INHTS | 85416000 |
| MXHTS | 8541.60.01 |
