MICROCHIP APTC80H29T3G

MICROCHIP APTC80H29T3G

Name: MICROCHIP APTC80H29T3G
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: APTC80H29T3G

Package: -

Customer #:

Description: 800V 15A 290mΩ@10V,7.5A 3.9V@1mA 4 N-Channel 156W Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP APTC80H29T3G

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

MICROCHIP

Package:

Configuration:

Drain to Source Voltage:

800V

Current - Continuous Drain(Id):

15A

Operating Temperature -:

-40℃~+150℃

RDS(on):

290mΩ@10V,7.5A

Gate Threshold Voltage (Vgs(th)):

3.9V@1mA

Type:

Reverse Transfer Capacitance (Crss@Vds):

54pF

Number:

4 N-Channel

Output Capacitance(Coss):

1.046nF

Input Capacitance(Ciss):

2.254nF

Pd - Power Dissipation:

156W

Gate Charge(Qg):

90nC@10V

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	1
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
