MICROCHIP MSCSM170HM087CAG

MICROCHIP MSCSM170HM087CAG

Name: MICROCHIP MSCSM170HM087CAG
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: MSCSM170HM087CAG

Package: -

Customer #:

Description: 1.7kV 238A 11.3mΩ@20V,120A 3.2V 4 N-Channel 1.114kW Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP MSCSM170HM087CAG

Products Specifications

Manufacturer:

MICROCHIP

Package:

Drain to Source Voltage:

1.7kV

Current - Continuous Drain(Id):

238A

RDS(on):

11.3mΩ@20V,120A

Operating Temperature -:

-40℃~+175℃@(Tj)

Gate Threshold Voltage (Vgs(th)):

3.2V

Number:

4 N-Channel

Pd - Power Dissipation:

1.114kW

Input Capacitance(Ciss):

13.2nF@1000V

Gate Charge(Qg):

712nC@20V

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
