MICROCHIP APTM50H10FT3G
Manufacturer:
MICROCHIP
Mfr. Part #:
APTM50H10FT3G
Package:
-
Customer #:
Description:
500V 37A 120mΩ@10V,18.5A 5V@1mA 4 N-Channel 312W Single FETs, MOSFETs RoHS
Datasheet:
MICROCHIP APTM50H10FT3G
Products Specifications
Manufacturer:
Package:
-
Configuration:
-
Drain to Source Voltage:
500V
Current - Continuous Drain(Id):
37A
Operating Temperature -:
-40℃~+150℃
RDS(on):
120mΩ@10V,18.5A
Gate Threshold Voltage (Vgs(th)):
5V@1mA
Type:
-
Reverse Transfer Capacitance (Crss@Vds):
61pF
Number:
4 N-Channel
Output Capacitance(Coss):
894pF
Input Capacitance(Ciss):
4.367nF
Pd - Power Dissipation:
312W
Gate Charge(Qg):
96nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
MICROCHIP
24560 Products
Microchip Technology
- Microchip Technology Inc. is a leading provider of microcontroller and analog semiconductors, providing low-risk product development, lower total system cost and faster time to market for thousands of diverse customer applications worldwide. Headquartered in Chandler, Arizona, Microchip offers outstanding technical support along with dependable delivery and quality.
