MICROCHIP APTM100H45FT3G
Manufacturer:
MICROCHIP
Mfr. Part #:
APTM100H45FT3G
Package:
-
Customer #:
Description:
1kV 18A 540mΩ@10V,9A 5V@2.5mA 357W Single FETs, MOSFETs RoHS
Datasheet:
MICROCHIP APTM100H45FT3G
Products Specifications
Manufacturer:
Package:
-
Configuration:
Half-Bridge
Drain to Source Voltage:
1kV
Current - Continuous Drain(Id):
18A
Operating Temperature -:
-40℃~+150℃
RDS(on):
540mΩ@10V,9A
Gate Threshold Voltage (Vgs(th)):
5V@2.5mA
Type:
-
Reverse Transfer Capacitance (Crss@Vds):
120pF
Number:
-
Output Capacitance(Coss):
715pF
Input Capacitance(Ciss):
4.35nF
Pd - Power Dissipation:
357W
Gate Charge(Qg):
154nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
