MICROCHIP APTC60HM24T3G
Manufacturer:
MICROCHIP
Mfr. Part #:
APTC60HM24T3G
Package:
-
Customer #:
Description:
600V 95A 24mΩ@10V,47.5A 3.9V@5mA 462W Single FETs, MOSFETs RoHS
Datasheet:
MICROCHIP APTC60HM24T3G
Products Specifications
Manufacturer:
Package:
-
Configuration:
Half-Bridge
Drain to Source Voltage:
600V
Current - Continuous Drain(Id):
95A
Operating Temperature -:
-40℃~+150℃
RDS(on):
24mΩ@10V,47.5A
Gate Threshold Voltage (Vgs(th)):
3.9V@5mA
Type:
N-Channel
Reverse Transfer Capacitance (Crss@Vds):
-
Number:
-
Output Capacitance(Coss):
17nF
Input Capacitance(Ciss):
14.4nF
Pd - Power Dissipation:
462W
Gate Charge(Qg):
300nC@10V
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | EAR99 |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
About Product
Get Best Price
Inquiry
Negotiate
Payment
Shipping
MICROCHIP
24560 Products
Microchip Technology
- Microchip Technology Inc. is a leading provider of microcontroller and analog semiconductors, providing low-risk product development, lower total system cost and faster time to market for thousands of diverse customer applications worldwide. Headquartered in Chandler, Arizona, Microchip offers outstanding technical support along with dependable delivery and quality.
