MICROCHIP MSC180SMA120SA

MICROCHIP MSC180SMA120SA

Name: MICROCHIP MSC180SMA120SA
Brand: MICROCHIP

Manufacturer: MICROCHIP

Mfr. Part #: MSC180SMA120SA

Package: D2PAK-7

Customer #:

Description: 1.2kV 21A 225mΩ@20V 5V@500uA 147W D2PAK-7 Single FETs, MOSFETs RoHS

Datasheet: MICROCHIP MSC180SMA120SA

Products Specifications

Category:

Discrete Semiconductors/FETs, MOSFETs/Single FETs, MOSFETs

Manufacturer:

MICROCHIP

Package:

D2PAK-7

Drain to Source Voltage:

1.2kV

Current - Continuous Drain(Id):

21A

Operating Temperature -:

-55℃~+175℃

RDS(on):

225mΩ@20V

Gate Threshold Voltage (Vgs(th)):

5V@500uA

Type:

N-Channel

Reverse Transfer Capacitance (Crss@Vds):

4pF

Pd - Power Dissipation:

147W

Input Capacitance(Ciss):

481pF

Output Capacitance(Coss):

47pF

Gate Charge(Qg):

36nC@20V

Additional Information

Type	Details
Minimum	1
Multiple	1
Standard Packaging	50
Sales Unit	Piece

Compliance & Export Codes

Type	Details
RoHS
ECCN	EAR99
CNHTS	8541290000
USHTS	8541290095
TARIC	8541290000
CAHTS	8541290000
BRHTS	85412910
INHTS	85412900
MXHTS	8541.29.99
