Huixin H12N65IK
Manufacturer:
Huixin
Asian Brands
Mfr. Part #:
H12N65IK
Package:
TO-220AB
Customer #:
Key Attributes:
MOSFET 650V 12.3A TO-220AB
Description:
650V 12.3A 278mΩ@10V 1 N-channel 106W TO-220AB Single FETs, MOSFETs RoHS
Datasheet:
Huixin H12N65IK
Products Specifications
Manufacturer:
Package:
TO-220AB
Drain to Source Voltage:
650V
Current - Continuous Drain(Id):
12.3A
RDS(on):
278mΩ@10V
Operating Temperature -:
-55℃~+150℃
Reverse Transfer Capacitance (Crss@Vds):
1.8pF
Number:
1 N-channel
Input Capacitance(Ciss):
870pF
Pd - Power Dissipation:
106W
Output Capacitance(Coss):
54pF
Gate Charge(Qg):
19nC@10V
Additional Information
| Type | Details |
|---|---|
| Minimum | 1 |
| Multiple | 1 |
| Standard Packaging | 50 |
| Sales Unit | Piece |
Compliance & Export Codes
| Type | Details |
|---|---|
| RoHS | |
| ECCN | - |
| CNHTS | 8541290000 |
| USHTS | 8541290095 |
| TARIC | 8541290000 |
| CAHTS | 8541290000 |
| BRHTS | 85412910 |
| INHTS | 85412900 |
| MXHTS | 8541.29.99 |
